Here’s how to make your very own custom circuit board/PCB! When we start learning a new skill, we don’t know what we don’t know. What should you Google search? It’s hard to say! This beginner’s guide solves that for you even if you know nothing of basic electronics. Follow along and learn from the exact resources I used when discovering my love of electronic design.

Join me.

– Chapters –
00:00 – What We’ll Cover
00:38 – Learning Basic Electronics
02:00 – Prototyping on a Breadboard
02:56 – Hand Soldering on Perfboard
04:25 – Learning KiCad
05:38 – Ordering Circuit Boards
07:02 – Project Examples and How to Support the Channel
